640mm Mimaki UV Printer UJV300DTF-75 UV DTF Printing Machine

Name: 640mm Mimaki UV Printer UJV300DTF75 UV DTF Printing Machine
Brand: MIMAKI
Price: 1 USD

Quality 640mm Mimaki UV Printer UJV300DTF-75 UV DTF Printing Machine for sale

Brand Name : MIMAKI

Model Number : UJV300-75

Certification : CE

Place of Origin : Japan

MOQ : Negotiable

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100sets one month

Delivery Time : 7-15 Working Days

Packaging Details : Standard Packaging

product name : Flatbed UV Printer

Brand : MIMAKI

feature : High precision

Contact Now

MIMAKI Create High Value-Add Printing Business UJV300DTF-75 UV-DTF Printer

Product Description

UV-DTF : Create High Value-Add Printing Business

"UJV300DTF-75" is a Mimaki's first UV-DTF (UV curable – Direct To Film) printer.

UV-DTF is a decoration method in which a design printed on a special film is transferred to the target material. It can easily decorate the surface of materials with uneven or curved surfaces, which has been difficult with conventional UV printing.

UV-DTF's exclusive film consists of two parts: a glued film and a transfer sheet.

UV-DTF eliminates the need for weeding (removal of margins) manually and allows confirmation of printed content before transfer, which significantly improves production efficiency and waste rates.

Specifications

UJV300DTF-75
Print head		On-demand piezo head
Print resolution		300dpi, 600dpi, 900dpi, 1200dpi
Ink	Type/Color	UV curable flexible ink ELS-170 (C, M, Y, K) UV curable hard ink ELH-100 (White, Clear)
Ink	Capacity	1L bottle
Ink circulation system		Available only for white ink
Max. print width		640 mm (25.2 in)
Media	Max. width	650 mm (25.6 in)
	Roll diameter	φ250 mm (9.8 in) or less
	Roll weight	45 kg (99.2 lb) or less
Interface		USB2.0 / Ethernet 1000 BASE-T
Certifications		VCCI class A / FCC class A / ETL IEC 62368-1 / CE Marking (EMC, Low voltage, Machinery directive and RoHS) / CB / REACH / Energy Star / RCM / KC
Power supply		Single-phase AC100-120 / 200-240V±10%, 50/60Hz±1Hz x 1
Power consumption		AC100V: 1.44kW or less / AC200V: 1.92kW or less
Operational environment		Temperature: 20-30 degC / 68-86 degF Humidity: 35-65% Rh (Non condensing)
Dimensions (W×D×H)		2,090 x 930 x 1,475 mm (82.3 x 36.6 x 58.1 in)
Weight		180 kg (396.8 lb)
